Develop and manufacture environmentally friendly filter materials such as PTFE coated materials, PET non-woven fabrics, PP non-woven fabrics, etc.
| Technical parameters of PTFE waterproof and breathable membrane material | ||||||
|
Model |
Colour |
Thickness （mm） |
Air permeability (ml/cm2/min@7KPa) |
Protection grade | Temperature resistance range（℃） | Notes |
|
LY-BS-120 |
White |
0.15 | 1500-1200 | IP68 | -40-125 | |
| LY-BS-150 | White | 0.15 | 1200-1500 | IP68 | -40-125 | |
| LY-BS-200 | White | 0.15 | 1500-2000 | IP68 | -40-125 | |
| LY-BS-250 | White |
0.15 |
2000-2500 |
IP67 | -40-125 | |
| LY-BS-600 | White | 0.15-0.2 | 5000-6000 | IP65 | -40-125 | |
| LY-BS-003 | White | 0.03-0.05 | 1200-1500 | IP67 | -40-125 | |
| LY-BS-005 | White | 0.05-0.08 | 800-1500 | IP67 | -40-125 | |
| LY-HS-015 | Grey | 0.15-0.2 | 300-400 | IP68 | -40-125 | |
| LY-BS-6 | Black | 0.1 | 25000-26000 | IP54 | -40-125 | |
|
The above regular models do not meet your needs. We can also customize production according to the parameters you need |
||||||
|
Testing standards |
||||||
|
1.Breathability: ASTM D737- 1996 |
||||||
|
2.Water pressure resistance: ISO811 |
||||||
|
Application area |
||||||
|
This series of waterproof and breathable films can be applied to car lights, sensitive electronic components in automobiles, outdoor lighting, outdoor electronic devices, as well as household appliances and electronics. |
||||||
-
Solar photovoltaic
-
Automotive industry
-
Communication industry
-
Security industry
-
Lighting industry
-
Home appliance industry
-
Electronic industry
-
Transmission industry
-
Container industry
