Develop and manufacture environmentally friendly filter materials such as PTFE coated materials, PET non-woven fabrics, PP non-woven fabrics, etc.
| Technical parameters of melt blown composite materials | |||
| The following regular models do not meet your needs. We can also customize production according to the parameters you need | |||
Material name | |||
H11 grade impregnation melt blown composite | |||
Test conditions | |||
Test temperature | Relative humidity | ||
(20-23)℃ | (70±5)% | ||
Technical parameters and testing standards | |||
| Project | Unit | Technical Parameter | Test reference standards |
| Color | / | White | Visual |
| Quantify | g/m2 | 70±10 | ISO 9073-1 |
| Thickness | mm | 0.45±0.06 | ISO 9073-2 |
| Resistance | Pa | ≤50 | |
| Filtration efficiency | % | ≥95 | |
Test method Enumeration Flow volume：5.3 cm/s Size Range：0.3μm AerosolNACL | |||
Application area | |||
This PP melt blown composite filter material adopts a unique process, using polypropylene special resin as raw material and high-temperature melt blown composite process to form the filter material. Widely applicable for manufacturing various filters, such as general ventilation W-type non partition filters, automotive air conditioning filters, vacuum cleaner filters, air purifier filters, and high-efficiency specialized filters. | |||
Air purifier filter
vacuum cleaner filter
car air conditioning filter
industrial ventilation filter
